Become your trustworthy partner in the field of plastic processing automation process.
2 Years
| Ask Lasest Price | |
| Brand Name : | DEGA |
| Model Number : | ECO Cost-effective Series |
| Certification : | CE, IOS 9001: 2015 |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 15 Sets per Month |
| Delivery Time : | 45 work days |
Product Introduction:
ECO series models, specific torque 9N.m/cm3, economical models.
Intelligent Control System:
Wear and Corrosion Resistant Solutions:
We offer wide range of MoC for barrels, screw elements and shafts. With out exclusively developed extremely wear and corrosion resistant material, the service life of barrels could be extended several times compared to HIP material for compounding polymers with glass and carbon fibers, ceramic and metal masses, and inorganic fillers.
Specifications:
| Model | Ratio [Do/Di] | Specific Torque [Nm/cm³] | Max. Speed [rpm] | Max. Torque [Nm] | Max. Motor Power [KW] |
| ECO35 | 1.51 | 9 | 900 | 2x238 | 45 |
| ECO50 | 1.55 | 9 | 900 | 2x584 | 110 |
| ECO65 | 1.55 | 9 | 900 | 2x1167 | 220 |
| ECO75 | 1.51 | 9 | 900 | 2x1883 | 355 |
| ECO96 | 1.55 | 9 | 600 | 2x3979 | 500 |
| ECO50/150(T+S) | / | / | 600(T)/70(S) | / | 90(T)/45(S) |
| ECO65/180(T+S) | / | / | 600(T)/70(S) | / | 160(T)/55(S) |
| ECO75/200(T+S) | / | / | 600(T)/70(S) | / | 250(T)/75(S) |
| ECO96/250(T+S) | / | / | 600(T)/70(S) | / | 500(T)/110(S) |
Application Field:
Suitable for various modified material applications.
Extruder Service:
More than just machine maintenance, we offer full cooperation.
|
