304 Stainless Steel Hopper 7L SS Hopper Process And Maintenance

Ask Lasest Price
Brand Name :	DEGA
Payment Terms :	L/C, T/T
Delivery Time :	30 work days
Certification :	CE, IOS 9001: 2015
Price :	Negotiable
Supply Ability :	50 Sets per Month

Add to Cart

Product Details
Company Profile

304 Stainless Steel Hopper 7L SS Hopper Process And Maintenance

Process and Maintenance Hoppers

Product Introduction

The process hoppers are designed to maximize the chimney effect that the hot air produces while going through the granules: they are made of finely polished Aisi 304 stainless steel and are insulated with rock fibre, externally coated with a sheet of satined aluminium. The large opening present on most of the models, facilitates an extensive and thorough cleaning, while ensuring with quick snap closures always a perfect tightness.

Our product also include insulated hoppers to prevent sudden cooling of the plastic material.

INSULATION OUTLINE DRAWING

304 Stainless Steel Hopper 7L SS Hopper Process And Maintenance

INSULATION CONNECTOR DIMENSION


MOD.	G1	G2	G3-5	G3-10	G5	G5-5	G5-10	G5-15	G5-30
A	110	143	262	387	175	250	332	412	657
B	215	280	280	280	330	330	330	330	330
D	60	60	60	60	60	60	60	60	60
E	100	140	140	140	140	140	140	140	140
G	80	102	102	102	102	102	102	102	102
I	172	222	222	222	28	285	285	285	285
L	7	7	7	7	7	7	7	7	7
Flangia	2	2	2	2	2	2	2	2	2

TI OUTLINE DRAWING

304 Stainless Steel Hopper 7L SS Hopper Process And Maintenance

TI OUTLINE DIMENSION


TI	A	B	C	D	E	F	G	H	I	L	M
TI30	675	485	-	55	180	140	150	110	380	60	-
TI60	950	485	-	55	180	140	150	110	380	60	-
TI100	1320	579	-	85	240	180	210	150	473	60	-
TI150	1390	579	-	85	240	180	210	150	473	60	-
TI200	1440	656	398	85	240	180	210	150	550	60	756
TI250	1690	656	398	85	240	180	210	150	550	60	756
TI300	1890	656	398	85	240	180	210	150	550	60	756
TI350	1840	736	469	85	240	180	210	150	550	60	836
TI400	1940	736	469	85	240	180	210	150	550	60	836
TI500	2190	736	469	85	240	180	210	150	550	60	836
TI600	2040	886	565	85	240	180	210	150	780	70	985
TI700	2215	886	565	116	360	230	320	190	780	70	985
TI800	2365	886	565	116	360	230	320	190	780	70	985
TI11000	2790	886	565	116	360	230	320	190	780	70	985

TI	A	B	C	D	E	F	G	H	I	L	N
1500	4140	1042	1310	180	300	300	270	270	936	129	1310
2000	3590	1193	1460	180	300	300	270	270	1087	129	1460
2500	4140	1193	1460	180	300	300	270	270	1087	129	1460
3000	4190	1470	1810	180	300	300	270	270	1270	129	1725
5000	5270	1600	1930	180	300	300	270	270	1400	129	1853

MODEL SELECTION CHART


	AC15	AC30	DD30	DD60	DD70	DD80	DD110
	Kg/h	Kg/h	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.
ABS	3	6	20 150	40 300	55 350	60 300	75 350
CA	3	5	15 100	30 250	40 300	45 300	55 300
CAB	3	5	13 100	25 200	35 300	40 250	50 300
CP	3	6	15 100	25 150	39 250	42 200	50 200
EPDM	2	5	12 100	24 200	32 250	36 250	50 300
EVA	1	3	15 150	28 250	33 300	40 300	50 350
LCP	2	5	25 200	45 400	65 600	70 500	90 600
PA	3	7	15 150	30 300	40 400	45 350	55 400
PA 30%GF	5	10	16 100	32 200	43 250	48 250	58 300
PA40%GF	5	10	16 100	32 200	43 250	48 250	58 300
PBT	3	5	20 150	40 300	53 400	60 350	73 400
PC	3	5	26 150	52 300	62 350	70 300	85 350
PE	9	18	20 30	40 60	60 100	65 100	80 150
PE(BL)	2	5	15 100	25 150	36 250	40 200	50 250
PEEK	2	5	23 200	46 400	50 400	60 400	75 500
PEI	2	3	23 100	46 400	60 500	75 500	90 600
PEN	2	4	14 100	30 250	39 300	43 250	52 300
PES	4	7	20 150	40 300	55 400	60 350	70 400
PET(EXT)	4	9	15 150	30 300	38 350	43 300	50 350
PET(INJ)	4	9	25 150	50 300	67 400	75 350	97 450
PETG	9	18	20 250	40 500	45 600	50 500	68 700
PI	5	9	23 150	46 300	67 400	80 400	97 500
PMMA	2	5	25 150	50 300	50 300	57 350	76 350
POM	9	18	25 150	50 300	53 350	60 300	70 350
PP	2	4	25 60	40 100	55 150	65 150	73 150
PPO	3	5	20 100	40 200	57 300	64 250	79 300
PPS	9	18	23 200	46 400	60 500	72 500	90 600
PS	3	5	25 60	40 100	75 200	75 150	100 200
PSU	5	10	25 200	50 400	63 500	67 400	81 500
PUR	4	7	18 100	36 200	45 250	50 200	60 250
PVC	4	8	23 60	50 150	60 150	70 150	95 200
SAN	3	6	25 200	50 400	65 500	67 500	85 500
SB	5	9	25 100	50 200	60 250	65 200	88 300
TPE	4	7	16 100	32 200	35 200	45 200	50 200
TPU	2	4	11 100	22 200	25 200	30 200	37 250

	DD180	DD260	DD350	DD500	DD900	DD1500
	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.	Kg/h Lt.
ABS	120 600	170 800	240 1200	340 1700	600 3000	1000 5000
CA	85 500	120 700	170 1000	250 1500	430 2500	760 4500
CAB	75 400	110 700	160 1000	235 1500	430 2500	700 4200
CP	800 400	100 500	157 800	220 1100	400 2000	700 3500
EPDM	65 400	100 600	145 900	200 1200	370 2300	660 4000
EVA	75 500	100 700	150 1000	215 1500	380 2500	670 4500
LCP	135 900	190 1250	250 1650	390 2600	700 4600	1231 8200
PA	990 700	130 800	185 1500	255 2000	455 3500	800 6000
PA30%GF	95 500	132 700	189 1000	280 1500	480 2500	845 4500
PA40%GF	95 500	132 700	189 1000	280 1500	480 2500	845 4500
PBT	1250 700	170 1000	250 1500	340 2000	610 3500	1060 6000
PC	138 600	190 800	277 1200	400 1700	700 3000	1220 5000
PE	120 200	173 300	240 400	350 600	600 1000	1100 1800
PE(BL)	80 400	120 600	160 800	220 1100	400 2000	680 3500
PEEK	120 800	160 1100	240 1600	340 2250	600 4000	1050 7000
PEI	135 900	200 1300	280 1900	392 2600	700 4500	1200 8000
PEN	85 500	120 700	171 1000	260 1500	433 2500	762 4500
PES	120 700	160 900	230 1300	330 2000	600 3500	1050 6000
PET(EXT)	85 600	125 900	170 1200	243 1700	433 3000	765 5500
PET(INJ)	150 700	215 1000	300 1400	425 2000	750 3500	1300 6000
PETG	100 700	150 1500	2150 2200	300 3000	535 5300	945 9500
PI	140 700	205 1000	300 1500	420 2000	758 3700	1300 6500
PMMA	110 500	175 800	240 1100	340 1500	607 2008	1100 5000
POM	120 600	160 800	240 1200	340 1700	607 3000	1100 5500
PP	125 250	175 350	245 500	345 700	607 1200	1067 2200
PPO	125 500	179 700	257 1000	370 1500	650 2600	1140 4500
PPS	135 900	195 1300	277 1800	392 2600	700 4600	1231 8200
PS	150 300	200 4000	300 600	450 900	750 1500	1300 2600
PSU	130 800	185 1100	267 1600	380 2300	675 4150	1200 7400
PUR	92 400	140 600	190 800	270 1150	480 2000	850 3600
PVC	145 300	200 400	300 600	400 800	700 1400	1200 2400
SAN	130 800	185 1100	267 1600	375 2200	670 4000	1185 7100
SB	125 400	185 600	270 900	378 1250	674 2250	1185 4000
TPE	85 350	119 500	170 730	240 1000	430 1850	762 3250
TPU	55 400	70 500	95 700	150 1100	270 2000	470 3400
